Insulation Accessories
Poly Lock
High-performance eco-certified engineering solution
Product Overview
Poly Lock provides a reliable and permanent connection between HDPE geomembranes and concrete structures. Manufactured from premium HDPE resin with a minimum of 2% carbon black for enhanced UV resistance and durability, the profile features three integrated T-shaped anchors that become embedded into concrete during casting. This creates a strong mechanical bond, ensuring long-term performance in demanding civil engineering, environmental, and water containment projects.
Technical Specifications
| Parameter / Specification | Technical Value |
|---|---|
| Material | High Density Polyethylene (HDPE) |
| Carbon Black Content | Minimum 2% |
| Profile Type | E-Profile |
| Thickness | 4 mm |
| Width | 150 mm |
| Anchor Finger Length | 25 mm |
| Node Width | 12 mm |
| Rod Length | 4 m |
| UV Resistant | Yes |
Key Applications
- Secure HDPE liner anchoring
- Strong mechanical bond with concrete
- Triple T-shaped anchor design
- Excellent sealing performance
- Ideal for waterproofing systems
- Suitable for landfill containment
- Ponds and lagoons
- Agricultural applications
- Aquaculture facilities
- Oil and gas industry
- Transportation infrastructure
- Water storage reservoirs
- Environmental remediation projects
- Durable HDPE construction
- UV resistant
- Long service life
- Low maintenance
- Easy installation during concrete casting
