Limaflex®
Sturdy Aluminum Support Profile
Product Overview
Limaflex® is a sturdy aluminium support profile designed for clean and stable edges of pathways and paved areas. It provides lateral support for patio and walkway slabs, flagstones, grit, split and lawn-grating slabs, and can also be used as a frame for asphalt areas.
The profile is also suitable for lawn and flowerbed edging as well as green roof applications. Its flexible construction allows it to be bent into arches and free forms without special tools, enabling individual layouts with radii of approximately 1.5 m and above, depending on the profile type.
Limaflex® offers quick and easy installation and connection, with individually adjustable 90° profile anchors as well as concrete and ground anchors. Its corrosion-resistant and recyclable aluminium alloy provides a durable and reusable solution for landscaping and hardscape applications.
Technical Specifications
| Parameter / Specification | Technical Value |
|---|---|
| Material | Aluminium alloy EN AW-6060 |
| Surface | Natural finish silver-grey aluminium |
| Profile Heights | 55 mm, 120 mm and 200 mm |
| Profile Thickness | 5.5 mm and 10 mm |
| Available Lengths | 2,500 mm and 5,000 mm |
| Corrosion Resistance | Corrosion-resistant aluminium alloy |
| Recyclable Material | Recyclable aluminium alloy |
| Installation | Quick and easy installation without special tools |
| Installation Type | Straight, curved and free-form installations |
| Profile Connection | Concrete/ground anchors and section connectors |
| Profile Anchors | Individually adjustable 90° profile anchors |
| Anchor Compatibility | Concrete and ground anchors |
| Green Roof Compatible | Yes, particularly with 55 mm and 120 mm profiles |
| Bending Radius | Approximately 1.5 m and above, depending on profile type |
Key Applications
- Path limitations
- Pavement boundary fixations
- Lawn edging
- Flowerbed edging
- Lawn-grating slab edging
- Roof gardens
- Paving and walkway edges
- Gravel and crushed stone areas
- Asphalt area framing
- Curved and free-form landscape layouts
