Water Saving Systems

Tree Resevoir

Underground Wicking Reservoir for Healthier Trees & Sustainable Planting

Product Overview

WaterUps Planters & Tree Reservoir™ is an innovative underground irrigation system developed to improve the establishment of trees and plants while significantly reducing water consumption and maintenance costs. Manufactured from 100% recycled polypropylene, it stores 15 liters of water beneath the root zone, delivering moisture through capillary action approximately 35 cm below the roots.

This system encourages deeper root development, making plants stronger, healthier, and more resilient during drought and extreme weather conditions. It is an ideal solution for municipalities, landscape architects, developers, commercial projects, and private gardens focused on sustainable landscaping.

Technical Specifications

Parameter / Specification	Technical Value
Material	100% Recycled Polypropylene (PP)
Manufacturing Process	High Precision Injection Molding
Color	Black
Reservoir Dimensions	40 × 40 × 13 cm
Installed Depth	Approximately 35 cm Below Roots
Water Capacity	15 Liters
Weight (Including Lid & Inlet Pipe)	2.5 kg
Wicks/Feet	4 per Module
Perlite Requirement	2 Liters per Module
UV Resistance	Yes
Chemical Resistance	Yes
Manufacturing Standard	ISO 9001
Recyclable	100%

Key Applications

Underground self-watering reservoir
Capillary irrigation technology
Reduces watering by up to 75%
Saves water and maintenance costs
Promotes deeper root development
Supports faster plant growth
Improves tree establishment
Reduces failure of young plants
Ideal for planter boxes
Suitable for trees and shrubs
Perfect for private gardens
Suitable for public spaces
Ideal for terraces
UV resistant
Chemical resistant
Manufactured from 100% recycled polypropylene
Fully recyclable
Long service life
Low maintenance
